ASR 5000 Hardware Platform Overview

▀ Application Cards

▄ ASR 5000 Installation Guide

Figure 10. System Management Card (SMC)

Table 6. SMC Callouts

Item

Description

Card Ejector Levers —Use to insert/remove card to/from chassis.

Interlock Switch —Sliding this switch downward on an active SMC initiates an immediate switchover to the standby

SMC.

Card Level Status LEDs—Show the status of the card.

System Level Status LEDs—Show the status of overall system health and/or maintenance requirements.
