Chassis Installation

Equipment Rack Configuration ▀

ASR 5000 Installation Guide ▄

Figure 23. System Airflow and Ventilation

Proper ventilation and cooling must allow the chassis to operate within the temperature and humidity levels described in

the following table.

Table 24. Operating Temperature and Humidity Recommendations

Operating Temperature

0 degrees C to +55 degrees C

Operating Humidity

20 percent to 80 percent, non-condensing
