Default SettingFeature
For low-speed NBMA networks: 180 seconds; all other networks:
15 seconds.
IP hold-time
Enabled.IP split-horizon
No summary aggregate addresses are predefined.IP summary address
tos: 0; k1 and k3: 1; k2, k4, and k5: 0Metric weights
None specified.Network
Enabled for IPv4 on switches running the Network Advantage
license. Allows Layer 3 switches to continue forwarding packets
from a neighboring NSF-capable router during hardware or
software changes.
Nonstop Forwarding (NSF) Awareness
Disabled.
The Device supports EIGRP NSF-capable routing for
IPv4.
Note
NSF capability
Disabled.Offset-list
Disabled.Router EIGRP
No metric set in the route map.Set metric
Distributed proportionately to the ratios of the metrics.Traffic-share
1 (equal-cost load-balancing).Variance
Configuring Basic EIGRP Parameters
Before You Begin
Procedure
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 1
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
109
Configuring IP Unicast Routing
Configuring Basic EIGRP Parameters

Cisco Catalyst 9500 Series Specifications

General

Series	Catalyst 9500 Series
Category	Switch
Software	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Fixed Uplink Modules	Varies by model
Stacking	Yes (StackWise Virtual)
Redundancy	Redundant power supplies and fans
Security	Advanced security features
PoE+	Available (varies by model)
Power Supply Options	AC and DC options (varies by model)
Relative Humidity	5% to 90% noncondensing
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Ports	Up to 48 ports (varies by model)
