PurposeCommand or Action
Returns to privileged EXEC mode.end
Example:
Device(config)# end
Step 13
Verifies your entries.show ip protocols
Example:
Device# show ip protocols
Step 14
(Optional) Saves your entries in the configuration file.copy running-config
startup-config
Step 15
Example:
Device# copy running-config
startup-config
Configuring RIP Authentication
RIP Version 1 does not support authentication. If you are sending and receiving RIP Version 2 packets, you
can enable RIP authentication on an interface. The key chain specifies the set of keys that can be used on the
interface. If a key chain is not configured, no authentication is performed, not even the default.
The Device supports two modes of authentication on interfaces for which RIP authentication is enabled: plain
text and MD5. The default is plain text.
Procedure
PurposeCommand or Action
Enables privileged EXEC mode. Enter your
password if prompted.
enable
Example:
Device> enable
Step 1
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 2
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
84
Configuring IP Unicast Routing
Configuring RIP Authentication
