Default IP Addressing Configuration
Table 5: Default Addressing Configuration
Default SettingFeature
None defined.IP address
No permanent entries in the Address Resolution Protocol (ARP) cache.
Encapsulation: Standard Ethernet-style ARP.
Timeout: 14400 seconds (4 hours).
ARP
255.255.255.255 (all ones).IP broadcast address
Enabled.IP classless routing
Disabled.IP default gateway
Disabled (all IP directed broadcasts are dropped).IP directed broadcast
Domain list: No domain names defined.
Domain lookup: Enabled.
Domain name: Enabled.
IP domain
If a helper address is defined or User Datagram Protocol (UDP) flooding is
configured, UDP forwarding is enabled on default ports.
Any-local-broadcast: Disabled.
Spanning Tree Protocol (STP): Disabled.
Turbo-flood: Disabled.
IP forward-protocol
Disabled.IP helper address
Disabled.IP host
Disabled.
Defaults when enabled:
•
Broadcast IRDP advertisements.
•
Maximum interval between advertisements: 600 seconds.
•
Minimum interval between advertisements: 0.75 times max interval
•
Preference: 0.
IRDP
Enabled.IP proxy ARP
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
59
Configuring IP Unicast Routing
Default IP Addressing Configuration

Cisco Catalyst 9500 Series Specifications

General

Series	Catalyst 9500 Series
Category	Switch
Software	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Fixed Uplink Modules	Varies by model
Stacking	Yes (StackWise Virtual)
Redundancy	Redundant power supplies and fans
Security	Advanced security features
PoE+	Available (varies by model)
Power Supply Options	AC and DC options (varies by model)
Relative Humidity	5% to 90% noncondensing
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Ports	Up to 48 ports (varies by model)
