PurposeCommand or Action
(Optional) Suppresses selected, more specific
routes.
aggregate-address address mask suppress-map
map-name
Example:
Device(config-router)# aggregate-address
10.0.0.0 255.0.0.0 suppress-map map1
Step 6
(Optional) Generates an aggregate based on
conditions specified by the route map.
aggregate-address address mask
advertise-map map-name
Example:
Device(config-router)# aggregate-address
10.0.0.0 255.0.0.0 advertise-map map2
Step 7
(Optional) Generates an aggregate with
attributes specified in the route map.
aggregate-address address mask
attribute-map map-name
Example:
Device(config-router)# aggregate-address
10.0.0.0 255.0.0.0 attribute-map map3
Step 8
Returns to privileged EXEC mode.end
Example:
Device(config)# end
Step 9
Verifies the configuration.show ip bgp neighbors [advertised-routes]
Example:
Device# show ip bgp neighbors
Step 10
(Optional) Saves your entries in the
configuration file.
copy running-config startup-config
Example:
Device# copy running-config
Step 11
startup-config
Configuring Routing Domain Confederations
You must specify a confederation identifier that acts as the autonomous system number for the group of
autonomous systems.
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
141
Configuring IP Unicast Routing
Configuring Routing Domain Confederations

Cisco Catalyst 9500 Series Specifications

General

Series	Catalyst 9500 Series
Category	Switch
Software	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Fixed Uplink Modules	Varies by model
Stacking	Yes (StackWise Virtual)
Redundancy	Redundant power supplies and fans
Security	Advanced security features
PoE+	Available (varies by model)
Power Supply Options	AC and DC options (varies by model)
Relative Humidity	5% to 90% noncondensing
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Ports	Up to 48 ports (varies by model)
