Cisco Catalyst 9500 Series User Manual

PurposeCommand or Action
Returns to privileged EXEC mode.end
Example:
Device(config)# end
Step 10
Verifies your entries.show ip protocols
Step 11
Example:
Device# show ip protocols
For NSF awareness, the output shows:
*** IP Routing is NSF aware *** EIGRP NSF
enabled
(Optional) Saves your entries in the configuration
file.
copy running-config startup-config
Example:
Device# copy running-config
Step 12
startup-config
Configuring EIGRP Interfaces
Other optional EIGRP parameters can be configured on an interface basis.
Procedure
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 1
Enters interface configuration mode, and specifies
the Layer 3 interface to configure.
interface interface-id
Example:
Device(config)# interface
gigabitethernet 1/0/1
Step 2
(Optional) Configures the percentage of bandwidth
that can be used by EIGRP on an interface. The
default is 50 percent.
ip bandwidth-percent eigrp percent
Example:
Device(config-if)# ip
bandwidth-percent eigrp 60
Step 3
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
111
Configuring IP Unicast Routing
Configuring EIGRP Interfaces

Cisco Catalyst 9500 Series Specifications

General

Series	Catalyst 9500 Series
Category	Switch
Software	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Fixed Uplink Modules	Varies by model
Stacking	Yes (StackWise Virtual)
Redundancy	Redundant power supplies and fans
Security	Advanced security features
PoE+	Available (varies by model)
Power Supply Options	AC and DC options (varies by model)
Relative Humidity	5% to 90% noncondensing
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Ports	Up to 48 ports (varies by model)
