Cisco Catalyst 9500 Series User Manual

Procedure
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Device# configure terminal
Step 1
Enables IP routing mode.ip routing
Example:
Device(config)# ip routing
Step 2
Names the VRF, and enter VRF configuration
mode.
ip vrf vrf-name
Example:
Device(config)# ip vrf vpn1
Step 3
Creates a VRF table by specifying a route
distinguisher. Enter either an AS number and an
rd route-distinguisher
Example:
Device(config-vrf)# rd 100:2
Step 4
arbitrary number (xxx:y) or an IP address and an
arbitrary number (A.B.C.D:y)
Creates a list of import, export, or import and
export route target communities for the specified
route-target {export | import | both}
route-target-ext-community
Step 5
VRF. Enter either an AS system number and an
Example:
Device(config-vrf)# route-target
import 100:2
arbitrary number (xxx:y) or an IP address and an
arbitrary number (A.B.C.D:y). The
route-target-ext-community should be the same
as the route-distinguisher entered in Step 4.
(Optional) Associates a route map with the VRF.
import map route-map
Example:
Device(config-vrf)# import map
importmap1
Step 6
(Optional) Enables global multicast routing for
VRF table.
ip multicast-routing vrf vrf-name
distributed
Example:
Device(config-vrf)# ip
Step 7
multicast-routing vrf vpn1 distributed
Routing Configuration Guide, Cisco IOS XE Everest 16.6.x (Catalyst 9500 Switches)
171
Configuring IP Unicast Routing
Configuring Multicast VRFs

Cisco Catalyst 9500 Series Specifications

General

Series	Catalyst 9500 Series
Category	Switch
Software	Cisco IOS XE
Operating Temperature	0°C to 45°C (32°F to 113°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Fixed Uplink Modules	Varies by model
Stacking	Yes (StackWise Virtual)
Redundancy	Redundant power supplies and fans
Security	Advanced security features
PoE+	Available (varies by model)
Power Supply Options	AC and DC options (varies by model)
Relative Humidity	5% to 90% noncondensing
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Ports	Up to 48 ports (varies by model)
