Citrix SD-WAN Platforms
The following tables summarize the specifications of the SD-WAN 1000 PE, 2000 PE, and 2100 PE plat-
forms.
Specifications SD-WAN 1000 PE SD-WAN 2000 PE SD-WAN 2100 PE
Bandwidth Up to 100 Mbps Up to 250 Mbps Up to 1 Gbps
Regulatory model
number
NS 6xCu NS 6xCu 1U1P1A
Processors 4 Core 4 Core 8 Core, 2.1 GHz
Solid State Drives
(SSD)
123 GB for Disk-Based
Compression (DBC);
25 GB for video
caching
225 GB for Disk-Based
Compression (DBC);
50 GB for video
caching
1X240 GB and 1X480
GB
Memory 32 GB 24 GB 32 GB
Number of power
supplies
1 power supply 1 power supply 1 power supply, 1
optional FRU
AC power supply
input voltage,
frequency, and
current
100 V ac to 240 V ac,
50–60 Hz, 1.7–3.4 A
100 V ac to 240 V ac,
50–60 Hz, 1.7–3.4 A
100 V ac to 240 V ac,
50–60 Hz, 1.7–3.4 A
DC power supply
input voltage and
current
-40 to -70 V DC, 4.8 to
8.6A
-40 to -70 V DC, 4.8 to
8.6A
-40 to -72 V DC, 4.8 to
8.6A
Maximum AC power
consumption
200 W 300 W 450 W
Airflow (front to rear) 22.1 CFM, Full: 76.2
CFM
22.1 CFM, Full: 76.2
CFM
22.1 CFM, Full: 76.2
CFM
Package weight (lbs.)
Shipping dimensions
and weight
26 L x 18.5 W x 6.5” H;
14.5 lbs
32 L x 23.5 W x 7.5” H;
39 lbs
33” L x 24” W x 8” H;
40 lbs
System weight (lbs.) 8.5 lbs (3.9 kgs) 32 lbs (14.5 kgs) 32 lbs (14.5 kgs)
Rack Units 1U 1U 1U
Width EIA 310-D, 19” EIA 310-D, 19” EIA 310-D, 19”
Depth 10” 25.4 cm 25.4” (64.5 cm) 28” (71.1 cm)
Operating
temperature
10–35 C 0–40 C 32–104 F (0–40 C)
