Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
• Power—When blinking, indicates that the power supply unit is receiving power and operating
normally.
The following figure shows the back panel of an SD-WAN 400 SE appliance.
Figure 2. SD-WAN 400 SE appliance, back panel
The following components are visible on the back panel of an SD-WAN 400 SE appliance:
• Cooling fan
• Single power supply, rated at 200 watts, 110–240 volts
• Accelerated pairs of Ethernet ports (apA and apB) which function as accelerated bridges. Indi-
vidual port assignments: LAN1 is apA.1, WAN1 is apA.2, LAN2 is apB.1, LAN2 is apB.2.
• RS-232 serial console port
• One Aux Ethernet port and one management port
• Two USB ports
• One Solid State Drive (SSD)
• SD-WAN 400 - 160 GB SSD
Citrix SD-WAN 410 SE
June 25, 2020
The SD-WAN 410 SE platform has a dual-core processor and 8 GB of memory. This platform has a
bandwidth of up to 150 Mbps.
The following figure shows the front panel of an SD-WAN 410 SE appliance.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 87

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
