Citrix SD-WAN Platforms
• Cooling fan - This platform is intended for use in a branch typically desktop mounted with am-
bient air temperature.
• Single power supply, rated at 200 watts, 110–240 volts. Power supply has an LED that indicates
the status of the power supply, as described in hardware-common-components-con1.html
• One RJ45 management port.
• One RJ45 console port.
• 6X1 GigE Copper (1000BASE-TX).
• VGA port.
• Two USB ports.
For information about installing the rails, rack mounting the hardware, and connecting the cables,
see “Installing the Hardware.”
For information about performing initial configuration of your appliance, see “Initial Configuration.”
Port labeling for SD-WAN 410
All data ports are labeled in the order they are enumerated by the Operating System. The ports use
odd port numbers for LAN ports and even port numbers for WAN ports. 1/1 is used for the first LAN
port, 1/2 for the first WAN port, 1/3 for the second LAN Port, 1/4 for the second WAN port, 1/5 for the
third LAN Port, and 1/6 for the third WAN Port.
Summary of Hardware Specifications
May 23, 2019
The following table summarizes the specifications of the SD-WAN 400 SE and 410 SE hardware plat-
forms.
Citrix SD-WAN 400 and 410 platforms specification summary
Hardware specifications
Feature SD-WAN 400 SE SD-WAN 410 SE
Processor 2 Cores 4 Cores
Total disk space 1 x 160 GB SSD 64 GB SATADOM
Total SSD and Compression
history (SSD)
40 GB 60 GB (compression history
(SSD) - N/A)
RAM 8 GB 8 GB
© 1999-2021 Citrix Systems, Inc. All rights reserved. 89
