Citrix SD-WAN Platforms
Rack Mount the Appliance
May 23, 2019
An SD-WAN 1000 PE (EE) or 2000 PE (EE) appliance requiresone rack unit. Botharerack-mount devices
that can be installed into two-post relay racks or four-post EIA-310 server racks. Verify that the rack is
compatible with your appliance.
Connecting the Cables
June 19, 2020
When the appliance is securely mounted on the rack, determine which ports you should use. You are
then ready to connect the cables. Ethernet cables and the optional console cable are connected first.
Connect the power cable last.
Warning: Before installing or repairing the appliance, remove all jewelry and other metal ob-
jects that might come in contact with power sources or wires. When you touch both a live power
source or wire and ground, any metal objects can heat up rapidly and cause burns, set clothing
on fire, or fuse the metal object to an exposed terminal.
Ports
A typical installation using a single accelerated bridge uses four Ethernet ports (the Primary port and
apA) and six IP addresses (four on the Primary port’s subnet and two on apA’s subnet).
The appliance has two motherboard ports and two accelerated bridges.
• The motherboard ports are labeled as MGMT (management) and AUX1 (auxiliary) ports in SD-
WAN 1000 appliance and PRI (primary) and AUX (auxiliary) in SD-WAN 2000 appliance. You use
MGMT port of the SD-WAN 1000 appliance and PRI port of the SD-WAN 2000 appliance for initial
configuration.
• Accelerated bridge ports are apA and apB are available on the back panel of SD-WAN 1000 ap-
pliance and the front panel of SD-WAN 2000 appliance. On SD-WAN 1000 appliance, these ports
are labeled as LAN1 and WAN1, and LAN2 and WAN2, respectively. However, on SD-WAN 2000
appliance, these ports are labeled as 1/1 and 1/2, and 1/3 and 1/4, respectively.
Connecting the ethernet cables
Ethernet cables connect your appliance to the network. The type of cable you need depends on the
type of port used to connect to the network. Use a category 5e or category 6 Ethernet cable with a
© 1999-2021 Citrix Systems, Inc. All rights reserved. 131
