Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
Specifications SD-WAN 1000 PE SD-WAN 2000 PE SD-WAN 2100 PE
Non-operating
temperature
-40 to +70 C -40 to +70 C 14F to 140F (-10C to
60C)
Humidity range
(non-condensing)
8%-90% 5%-95% 20%-80%
Safety certifications CSA/EN/IEC/UL
60950-1 Compliant,
UL, or CSA Listed
(USA and Canada), CE
Marking (Europe)
CSA/EN/IEC/UL
60950-1 Compliant,
UL, or CSA Listed
(USA and Canada), CE
Marking (Europe)
IEC 60950-1, second
Edition, CSA 60950-1,
second Edition, UL
60950-1, second
Edition, AS/NZS
6050-1
EMC & susceptibility FCC (Part 15 Class A),
CCC, KCC, NOM,
SASO, CITC, EAC, DoC,
CE, VCCI, RCM
FCC (Part 15 Class A),
CCC, KCC, NOM,
SASO, CITC, EAC, DoC,
CE, VCCI, RCM
US (FCC (Part 15 Class
A)), Europe (CE
(EN55032/ CISPR32),
Australia (RCM),
Japan (VCCI), Korea
(KCC), Taiwan (BSMI),
China (CCC), India
(BIS), Russia (EAC),
Saudi Arabia (CITC),
Brazil (Anatel), South
Africa (ICASA), Mexico
(NOM), Egypt (NTRA),
Israel (MoC)
Environmental
certifications
RoHS, WEEE RoHS, WEEE RoHS, WEEE
Ethernet Port Names
May 23, 2019
Specify IP addresses for various Ethernet ports of the appliance when configuring the appliance. The
Ethernet ports are labeled dierently on the front panel of SD-WAN 1000 PE and 2000 PE appliances
in the SD-WAN instance, as shown in the following table:
© 1999-2021 Citrix Systems, Inc. All rights reserved. 129

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
