Citrix SD-WAN Platforms
Switch on the Appliance
June 19, 2020
Aer you have installed the appliance in a rack and connected the cables, verify that the power cable
is properly connected. Aer verifying the connections, you are ready to switch on the appliance.
To switch on the appliance
1. Verify that the appliance is connected through a console or Ethernet port, so that you can con-
figure the appliance aer it is switched on.
2. Press the ON/OFF toggle power switch on the appliance.
3. On SD-WAN 2000 appliance, verify that the LCD on the front panel is backlit and the start mes-
sage appears
Caution: Be aware of the location of the emergency power o (EPO) switch, so that if an electrical
accident occurs, you can quickly remove power from the appliance.
Initial Configuration
May 23, 2019
Aer checking the connections, you are ready to deploy the SD-WAN 1000 and 2000 appliances on the
network.
The appliance shipped from Citrix has default IP addresses configured on it. To deploy the appliance
on the network, you must configure the appropriate IP addresses on the appliance to accelerate the
network traic.
To perform initial configuration:
• Identify the prerequisites for the initial configuration.
• Record various values required in the initial configuration procedure.
• Configure the appliance by connecting it to the Ethernet port.
• Perform more configuration for Windows.
• Assign management IP address through the serial console.
• Troubleshoot initial configuration issues.
By default, the initial configuration deploys the appliance in inline mode.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 133
