Citrix SD-WAN Platforms
that the drive locks securely into the slot.
Important: When you insert the drive, make sure that the Citrix product label is at the top if the
drive is inserted horizontally or at the right if the drive is inserted vertically.
Figure 2. Inserting the Replacement Solid-State Drive
5. Turn on the appliance.
6. Log on to the default IP address by using a web browser, or connect to the serial console by
using a console cable, to perform the initial configuration.
Hard Disk Drive
June 19, 2020
The Citrix SD-WAN virtual machines are hosted on the hard-disk drive.
Replace hard disk drive
Verify that the replacement hard disk drive is the correct type for the SD-WAN 4000/5000 platform.
To install a hard disk drive
1. Shut down the appliance.
2. Locate the hard disk drive on the back panel of the appliance.
3. Disengage the hard disk drive by pushing the safety latch of the drive cover to the right or down,
depending on the platform, while pulling out on the drive handle to disengage. Pull out the
faulty drive.
Figure 1. Removing the Existing Hard Disk Drive
© 1999-2021 Citrix Systems, Inc. All rights reserved. 417
