Citrix SD-WAN Platforms
• Single power supply, rated at 300 watts, 100-240 volts.
Citrix SD-WAN 2100 SE
June 25, 2020
The Citrix SD-WAN 2100-SE platform is a 1U appliance with 8 core processor and 32 GB (GB) of memory.
The following figure shows the front panel of the SD-WAN 2100-SE appliance.
Figure 1. Citrix SD-WAN 2100-SE appliance, front panel
SD-WAN 2100-SE appliance has the following ports:
• An RS232 serial console port.
• 10/100/1000 Base-T copper Ethernet management port (RJ45) called the Lights out Manage-
ment (LOM) port labeled LOM, and management port labeled 0/1. You can use these ports to
remotely monitor and manage the appliance independently of the appliance’s soware.
• USB ports.
• Four 1000 Base-TX copper Ethernet ports.
• Four 1GE SFP ports.
Port Labels - old 2100-SE Front Bezel Description
LOM Lights out management Port
0/1 Management Port
Port Labels - new 2100-SE Front Bezel Description
LOM 0/1 Lights out management and Management Port
0/2 Management port that is reserved for future
use (Management)
© 1999-2021 Citrix Systems, Inc. All rights reserved. 105
