Citrix SD-WAN Platforms
9. Power on the appliance to confirm that the BIOS configuration change has been applied suc-
cessfully. This can be either done through the APC intelligent PDU Web Management console
or by physically pulling the power cable out of the shut down SD-WAN appliance, waiting for
10 seconds and then plugging it back in again. The appliance power ups automatically from all
shut down scenarios.
Citrix SD-WAN WANOP 2000
June 19, 2020
The Citrix SD-WAN WANOP 2000 platform has 3 models: SD-WAN 2000-010, SD-WAN 2000-020, and
SD-WAN 2000-050, with bandwidths of 10 Mbps, 20 Mbps, and 50 Mbps, respectively. Each model is a
1U appliance with 1 quad-core processor and 24 gigabytes (GB) of memory.
The following figure shows the front panel of the SD-WAN WANOP 2000 appliance.
Figure 1. Citrix SD-WAN WANOP 2000, front panel
The appliance has the following ports:
• An RS232 serial console port.
• A copper Ethernet (RJ45) Port called the Lights out Management (LOM) port. You can use this
port to remotely monitor and manage the appliance independently of the appliance’s soware.
• A copper Ethernet (RJ45) management port, numbered 0/1. The management port is used to
connect directly to the appliance for system administration functions.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 15
