Citrix SD-WAN Platforms
To connect any of these ports to your network, you plug one end of a standard Ethernet cable into the
port and plug the other end into the appropriate network connector.
Management ports
Management ports are standard copper Ethernet ports (RJ45), which are used for direct access to the
appliance for system administration functions.
1G SFP and 10G SFP+ ports
• A 1G SFP port can operate at a speed of 1 Gbps. It accepts either a copper 1G SFP transceiver, for
operation as a copper Ethernet port, or a fiber 1G SFP transceiver for operation as a fiber optic
port.
• The 10G SFP+ ports are high-speed ports that can operate at speeds of up to 10 Gbps. You need
a fiber optic cable to connect to a 10G SFP+ port. If the other end of the fiber optic cable is
attached to a 1G SFP port, the 10G SFP+ port automatically negotiates to match the speed of the
1G SFP port.
Note
The SD-WAN 410-SE appliance can be used as a WAN optimization device, the first port pair has
an apA labeled.
The motherboard port is labeled MGMT for port Eth0.
Power Supply
January 28, 2020
Citrix SD-WAN appliances are configured with a single power supply. For an SD-WAN 3000 WANOP
appliance, you can order a second power supply.
Citrix SD-WAN 4000, 5000 WANOP/SE, 4100, and 5100 SE appliances are configured with dual power
supplies but can operate with only one power supply. The second power supply serves as a backup.
For an SD-WAN Standard Edition 410 appliance, a single chassis power switch is supplied. The device
has an external power brick instead of an internal power supply if a desktop form factor is chosen.
Table 1. LED Power Supply Indicators
© 1999-2021 Citrix Systems, Inc. All rights reserved. 412
