Citrix SD-WAN Platforms
standard RJ-45 connector on a 10/100/1000BASE-T port.
To connect an ethernet cable to a 10/100/1000BASE-T port
1. Insert the RJ-45 connector on one end of your Ethernet cable into an appropriate port. On SD-
WAN 1000 appliance, the ports are available on the back panel and labeled as LAN1 and WAN1
for apA bridged port for LAN and WAN links, respectively. On SD-WAN 2000 appliance, the ports
are available on the front panel. The ports on SD-WAN 2000 are labeled as 1/1 and 1/2 for the
apA bridged port. You can use 1/1 for LAN and 1/2 for WAN link.
2. Insert the RJ-45 connector on the other end into the target device, such as a router or switch.
3. Verify that the LED glows amber when the connection is established.
Connecting the console cable
You can use the console cable to connect your appliance to a computer or terminal, from which you
can configure the appliance. Before connecting the console cable, configure the computer or terminal
to support VT100 terminal emulation, 9600 baud, 8 data bits, 1 stop bit, parity, and flow control set to
NONE. Then connect one end of the console cable to the RS232 serial port on the appliance and the
other end to the computer or terminal.
To connect the console cable to a computer or terminal
1. Insert the DB-9 connector at the end of the cable into the console port. On SD-WAN 1000 ap-
pliance, the port is on the back panel. On SD-WAN 2000 appliance, the port is on the front
panel.
Note: To use a cable with an RJ-45 converter, insert the optional converter provided into
the console port and attach the cable to it.
2. Insert the RJ-45 connector at the other end of the cable into the serial port of the computer or
terminal.
Connecting the power cable
An SD-WAN appliance has one power supply. A separate ground cable is not required, because the
three-prong plug provides grounding. Provide power to the appliance by installing the power cord.
Connect the other end of the power cable to a standard 110V/220V power outlet.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 132
