Citrix SD-WAN Platforms
Specifications Citrix SD-WAN 6100 SE/PE
Number of power supplies 2 (Each 1,000 W; Dual Redundant Hot
swappable)
AC power supply, input voltage, frequency, and
current
100–240 V AC, 50–60 Hz, 5.5-2.8A
DC input voltage and Current -36 V DC to -72 V DC, 15.4-7.7A
Typical AC power consumption 357 W
Maximum AC power consumption 480 W
Typical Heat Dissipation 1251 BTU/Hr
Max Heat Dissipation 1218 BTU/Hr
Typical Airflow (front to rear) 65 CFM
Max Airflow (front to rear) 125 CFM
Altitude Range Max 5,000 m (Up to 16,000 )
Solid State Drives (SSD) 1x480GB and 3x960GB SSD (1.2GB DBC,
applicable for PE only)
Package weight 69 (lbs) (31.3 Kg)
Shipping dimensions 36.5’ L X 24.5’ W X 11’ H (94 x 63 x 28 cm)
System weight (lbs) 60 (lbs) (27.2 Kg)
Rack Height 2U
Rack Width EIA 310-D for 19 (inch) racks
Rack Depth 28 inches (71.1 cm)
Operating temperature 0–45°C (32–113°F)
Humidity (non-condensing) 5% - 95%
Safety certifications IEC 60950-1, second Edition
CSA 60950-1, second Edition
UL 60950-1, second Edition
AS/NZS 60950-1
© 1999-2021 Citrix Systems, Inc. All rights reserved. 146
