Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
Performing the installation procedures
Aer you have enabled the Hyper-V role on Microso Server and extracted the VPX files, you can use
Hyper-V Manager to install SD-WAN VPX. Aer you import the virtual machine, you must configure the
virtual NICs by associating them with the virtual networks created by Hyper-V.
Note: You cannot change any settings while the virtual appliance is running. Shut down the
virtual appliance and then make changes.
To install SD-WAN VPX on Microso Server 2012 by using Hyper-V Manager
1. Unzip the SD-WAN distribution that you downloaded from My Citrix.
2. Start Hyper-V Manager.
3. In the navigation pane, under Hyper-V Manager, select the server on which you want to install
SD-WAN VPX.
4. On the Actions menu, click **Import Virtual Machine.
5. In the Import Virtual Machine dialog box, in Location box, specify the path to the folder that
contains the SD-WAN VPX files.
Note: If you received a compressed file, make sure that you extract the files into a folder
before you specify the path to the folder.
6. Click Import.
7. Verify that the virtual appliance that you imported is listed under Virtual Machines.
8. Right-click the imported virtual machine, and then click Settings.
9. In the Settings window’s navigation pane, under Hardware, select the first network adapter in
the list.
10. In the Network drop-down menu, select apA1 Network. This is the LAN interface for apA1.
11. Make sure the Enable MAC address spoofing box is selected. If it is not, select it and apply the
changes.
12. In the Settings window’s navigation pane, under Hardware, select the second network adapter
in the list. Repeat the step 10 and step 11, and assign the adapter to apA2 Network. This is the
WAN interface for apA2.
Important: Do not configure the same Network for both the network adapters. Incorrect config-
uration creates packet loops, which can bring down the network.
13. Optionally, change the virtual hard disk size:
• In the Settings window navigation pane, under IDE Controller 0, select Hard Drive.
• Click Edit.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 231

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
