Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
Typical reach (m): 10 km
Applicable platforms:
• SD-WAN 1100 SE and PE
10 GE pluggable media
The following table lists the maximum distance specifications for 10G transceivers.
Short reach fiber 10G SFP+ distance specifications
Description
Transmitter
Wavelength (nm) Fiber Type Typical Reach (m)
10G SFP+, Ethernet
Short Range (300 m) -
Single
850 nm (nominal) 50/125um MMF,
2000MHz- km (OM3)
300 m
50/125um MMF,
500MHz-km (OM2)
82 m
50/125um MMF,
400MHz-km
66 m
62.5/125um MMF,
200MHz-km (OM1)
33 m
62.5/125um MMF,
160MHz-km
26 m
Long reach fiber 10G SFP+ distance specifications
Description:
10G SFP+ Ethernet long range (10 km) - Single
Transmitter wavelength (nm): 1310nm (nominal)
Fiber type: 9/125um SMF
Typical reach (m): 10km
Citrix direct attached (DAC) copper TwinAx 10G SFP+ passive cables
Description: 1m DAC SFP+ cable for up to 1m distance
Description: 3m DAC SFP+ cable for up to 3m distance
Description: 5m DAC SFP+ cable for up to 5m distance
© 1999-2021 Citrix Systems, Inc. All rights reserved. 406

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
