Citrix SD-WAN Series User Manual

Citrix SD-WAN Platforms
5. Install the adapter fix bracket to hold the power adapter in position. Place the adapter fix
bracket on the slot and fix it with a screw.
Installing the LTE antennas
To use the Citrix SD-WAN 110-LTE-WiFi-SE appliance as an LTE modem, install the antennas to the ap-
pliance. The antennas are included in the appliance package. The Citrix SD-WAN 110-LTE-WiFi-SE ap-
pliance has two SMA coax male connectors at the front and rear of the appliances. The antennas have
independent rotating SMA female connectors.
Note
Ensure that both the LTE antennas are installed for better LTE cellular connectivity.
To install the antennas to the appliance:
1. Place the antenna SMA coax connector (F) on the appliance SMA coax connector (M) and rotate
the antenna connector clockwise, until the connector is tight.
Note
The recommended torque is 1.8–2.5 Lbs force-inch.
© 1999-2021 Citrix Systems, Inc. All rights reserved. 65

Citrix SD-WAN Series Specifications

General

Product Type	SD-WAN Appliance
Product Series	SD-WAN
Network Interfaces	Gigabit Ethernet
Performance	Varies by model
Form Factor	Rackmount
Management	CLI
Throughput	Varies by model
Interfaces	Ethernet
VPN Support	IPsec, SSL VPN
High Availability	Yes
Security Features	Firewall
WAN Optimization	Application Acceleration, Data Deduplication, Compression
