Codan HF SSB User Manual

Link Setup mode
HF SSB transceiver reference manual 9-3
In normal transceiver operation, the link is in the parked
position. In Link Setup mode, the link is in the link setup
position.
The transceiver is muted and the PTT button is disabled in
Link Setup mode.
To use Link Setup mode:
Action Notes
1.
Ensure the transceiver
is switched off.
2.
Remove the bottom
cover by removing the
screws on either side
and lifting the cover
off.
The bottom cover usually has
four rubber feet fitted.
3.
Locate the link shown
in Figure 9.1 and move
it to the link setup
position.
The link is a small connector
that slides over two pins on the
board.
Pull it up gently to remove it.
4.
Switch on the
transceiver.
The display shows:
LINK SETUP MENU
1–Pin
2–Inhibit
ENTER
3–Antenna
4–Reset
The transceiver only detects a
changed link position when the
transceiver is first switched on.
Link Setup mode
HF SSB transceiver reference manual 9-3
In normal transceiver operation, the link is in the parked
position. In Link Setup mode, the link is in the link setup
position.
The transceiver is muted and the PTT button is disabled in
Link Setup mode.
To use Link Setup mode:
Action Notes
1.
Ensure the transceiver
is switched off.
2.
Remove the bottom
cover by removing the
screws on either side
and lifting the cover
off.
The bottom cover usually has
four rubber feet fitted.
3.
Locate the link shown
in Figure 9.1 and move
it to the link setup
position.
The link is a small connector
that slides over two pins on the
board.
Pull it up gently to remove it.
4.
Switch on the
transceiver.
The display shows:
LINK SETUP MENU
1–Pin
2–Inhibit
ENTER
3–Antenna
4–Reset
The transceiver only detects a
changed link position when the
transceiver is first switched on.
