Installation

HF SSB transceiver reference manual 2-9

To connect the control cable and loudspeaker cable to the

control head:

1. Remove the two screws on the rear of the control head

and remove the cover. Figure 2.3 shows the rear of the

control head with the cover removed.

2. Feed the loudspeaker cable through the foam grommet

near the control head end of the control cable.

3. Fit the cable clamp to the control cable and attach the

cable clamp to the inside of the rear cover of the control

head (as shown in the diagram on the inside of the rear

cover).

4. Plug the control cable into the 10-pin connector (the

cable only fits one way).

5. Plug the loudspeaker cable into the L/S loudspeaker

socket.

6. Place the foam grommet into the slot on the rear cover.

7. To make sure that the cover will not pinch the cable,

position the cable between the shaded areas in Figure

2.3.

8. Replace the rear cover of the control head and its two

screws carefully. Note that the rear cover of the control

head can be rotated to give you either top or bottom

entry of the cables.

The loudspeaker and the control head have similar mounting

brackets. The procedure for installing them is the same.

To install the brackets:

1. Remove the two cradle screws and washers securing the

mounting cradle to the equipment.

2. Secure the mounting cradle into position. Ensure that

there is sufficient space at the rear for the cables.

3. Secure the equipment to the mounting cradle with the

two screws and washers.
