Codan HF SSB User Manual

Appendix
11-12 HF SSB transceiver reference manual
To set up the interface:
Action Notes
1.
Remove the single
screw securing the back
cover of the interface
and remove the cover.
2.
Do you want to use the
GPS socket?
Yes  Step 3.
No  Step 5.
If you are not using this socket,
make sure that the GPS switch
is set to the on position (only
the On or Off position may be
marked).
3.
Set the GPS switch to
the off position.
The off position enables the
socket.
4.
Use the GPS A and
GPS B switches to set
the baud rate for the
GPS receiver.
Refer to the table above. The
most common setting is 4800
baud.
5.
Do you want to use the
COMPUTER socket ?
Yes  Step 6.
No  Step 8.
If you are not using this socket,
make sure that the COMP
switch is set to the on position
(only the On or Off position
may be marked).
6.
Set the COMP switch
to the off position.
The off position enables the
socket.
Appendix
11-12 HF SSB transceiver reference manual
To set up the interface:
Action Notes
1.
Remove the single
screw securing the back
cover of the interface
and remove the cover.
2.
Do you want to use the
GPS socket?
Yes  Step 3.
No  Step 5.
If you are not using this socket,
make sure that the GPS switch
is set to the on position (only
the On or Off position may be
marked).
3.
Set the GPS switch to
the off position.
The off position enables the
socket.
4.
Use the GPS A and
GPS B switches to set
the baud rate for the
GPS receiver.
Refer to the table above. The
most common setting is 4800
baud.
5.
Do you want to use the
COMPUTER socket ?
Yes  Step 6.
No  Step 8.
If you are not using this socket,
make sure that the COMP
switch is set to the on position
(only the On or Off position
may be marked).
6.
Set the COMP switch
to the off position.
The off position enables the
socket.
