InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 155
AMF26-P-2.4 Reference Guide.pdf
IL-NT
ID-Lite
IL-NT-
RS232
IL-NT-
RS232
IL-NT
ID-Lite
Remote Display Master controller
RS 232 (COM1)
Up to 10 meters:
It is recommended to use standard Null-modem cable for local connection between controller and
remote display, although the three wires (TxD, RxD, GND) RS 232 connection is enough for direct
communication:
IL-NT/ID-Lite
connector
D-SUB9 female
IL-NT-RD connector
D-SUB9 female
Remote RS485 and/or direct RS232 connection
HW module:
IL-NT-RS232-485
Up to 1000 meters (only with RS485):
