InteliLite
NT
AMF26-P, SW version 2.4, ©ComAp – January 2016 59
AMF26-P-2.4 Reference Guide.pdf
should be activated – either when only GCB is closed, only MCB is closed, either GCB or MCB is
closed or controller is in Ready To Load state.
See also Engine Params: Dummy Load ON/OFF
OverrideNeeded
The output closes when either Engine Temp (AI2) or Oil Pressure (AI1) warnings are activated and
automatically opens when both warnings are deactivated.
Maintenance
The output closes if the Maintenance alarm activates, i.e. the gen-set has been running for more than
Engine Protect:WrnMaintenance.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
Ctrl HeartBeat
The output signalizes Watchdog Reset. In a healthy state it blinks at 500ms : 500ms rate. When
Watchdog Reset occurs, it stops blinking.
Mode OFF
The output is closed, if OFF Mode is selected.
Mode MAN
The output is closed, if MAN Mode is selected.
Mode AUT
The output is closed, if AUT Mode is selected.
Mode TEST
The output is closed, if TEST mode is selected.
The output opens if:
x alarm is not active and
x FAULT RESET is pressed
AL D+ Fail
The output closes if gen-set is running and D+ input not energized.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
Hint:
Treshhold level for D+ input is 80% supply voltage.
AL Gen >V
The output closes if the generator overvoltage shutdown alarm activates.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
AL Gen <V
The output closes if the generator undervoltage shutdown alarm activates.
The output opens, if:
x alarm is not active and
x FAULT RESET is pressed
