BRIGHTNESS
Long press toggles from day to night palette. Short press brings up brightness level scale
on screen. Repeated short presses adjust brightness level in a loop.
WORK Special mode to adapt rudder offset angle and movement when engaged in special work
situations while at slow vessel speed. Work is only accessed when the pilot is in the
AUTO or NAV mode. See section on Work Mode. Double press for shortcut to WORK
menu from main SETUP menu.
NAV Turns the autopilot over to properly configured steering instructions coming from the ship’s
connected navigation system to follow an activated route or a single go to mark or
waypoint. N will appear on screen. When in NAV, press again to toggle back and forth
between 2 NAV screens. Double press for shortcut to NAV menu from main SETUP
menu.
AUTO A press of AUTO commands the autopilot to assume the compass heading that was being
read at the moment of press. A will appear on screen. Change course with KNOB. See
above. Double press for shortcut to AUTO menu from main SETUP menu.
CMD Short Press to take command from any other remote station. R will appear on the screen
if another station is in command.
Double press gains access to the complete menu trees for: System, Network Config.,
Setup and Factory.
If you are already in a menu, double press to exit menu or to go back to the previous
menu.
P-STR POWER STEER, a manual steering mode: When in P-Str, the vessel can be steered with
the ships steering wheel, the left right arrows, any connected NFU jog lever, or the course
change knob (see above). Double press for shortcut to P-Steer menu from main SETUP
menu.
ARROWS In AUTO mode, to avoid obstacles, the red arrow dodges the vessel to the left, the green
to the right. The rudder runs to the left or right as long as the operator holds an arrow
button down. When released, the autopilot steers the vessel back to the commanded
heading.
In P-STR mode, pressing an arrow key runs the rudder left or right as long as the button is
held down. The rudder stops when released and stays at that rudder angle until brought
back by the opposite arrow key, course change knob, jog lever, or steering wheel.
During DOCKSIDE setup an arrow click is used to make a selection.
TURN Double pressing the TURN mode button accesses the TURN shortcut menu. The TURN
menu has the options: Enable/disable special turn, Change turn, Pre-tack angle and
Fishzag time. A subsequent double press on the TURN mode button will exit the TURN
menu.
While in AUTO mode, a short press on TURN displays the default special turn, a
subsequent short press will shuffle to the next turn. To initiate the selected turn, press the
ARROW key corresponding to the desired turn direction. A short press on TURN after
turn has initiated will stop the turn.
