Monitoring Your CTERA Appliance 17
CTERA C-Series User Guide 289
Table 55: Status Dashboard Fields
All disk drives installed on the appliance.
For each drive, the following information is displayed:
The disk type
Click on this link to view additional information about the drive. For
further information, see Viewing Detailed Information About a Disk
Drive (on page 291).
The disk size in GB
The array to which the disk is assigned
The disk status. For a list of possible statuses, see Hard Drive
Statuses (page 290).
Note that you may notice a discrepancy between the disk capacity
stated on the disk's packaging and the disk capacity displayed in the
appliance Dashboard. This difference is due to the fact that vendors
define 1 GB as 1 billion (10
9
) bytes, while computers define 1 GB as 2
30
bytes.
All arrays defined on the appliance.
For each array, the following information is displayed:
The array name and RAID type
Click on this link to edit the array. For further information, see
Adding and Editing Arrays (on page 68).
The array size in GB
The array status. For a list of possible statuses, see Array Statuses
(page 290).
All volumes defined on the appliance.
For each volume, the following information is displayed:
The volume name and the storage device on which it is located.
Click on this link to edit the volume. For further information, see
Adding and Editing Logical Volumes (on page 73).
A bar representing of the percentage of the volume currently in use,
followed by the volume size in GB, followed by the percentage of
the volume currently in use.
The volume's status in the format: Mode [Status].
The mode can be Online or Offline. For a list of possible statuses,
see Volume Statuses (page 291).
The last five important events in the appliance Event Log.
