5.2.4 AXIS NAME
This parameter sets what text will be displayed on the LCD when the associated Actuator Axis is selected.
This is only applicable on Color Joystick Modules and the Omni.
ISM-8 – CHANNELS
5.2.4 ACCELERATION
This sets the acceleration rate for a particular ISM-8 channel.
Programmable range is 1 to 100 in steps of 1.
WARNING:
This parameter must be set to 100% on systems that use automatic endstops, i.e. those that do not use micro-switches at the
end of actuator travel. If the value is not set to 100%, then the automatic endstop function will not operate and damage to
the actuator motor or the wheelchair frame may occur.
5.2.5 DECELERATION
This sets the deceleration rate for a particular ISM-8 channel.
Programmable range is 1 to 100 in steps of 1.
WARNING:
This parameter must be set to 100% on systems that use automatic endstops, i.e. those that do not use micro-switches at the
end of actuator travel. If the value is not set to 100%, then the automatic endstop function will not operate and damage to
the actuator motor or the wheelchair frame may occur.
5.2.6 UP SPEED
This sets the speed of a particular ISM-8 channel in the Up direction.
Up is defined as pin 2 positive with respect to pin 1 when the joystick is displaced forward and Invert Axis Direction is not set.
Programmable range is 25% to 100% in steps of 1%.
