D-Link xStack DES-3528 Series Reference Guide

xStack® DES-3528/DES-3552 Series Layer 2 Managed Stackable Fast Ethernet Switch Web UI Reference Guide
120
By default, the robustness variable is set to 2. You might want to increase this value if
you expect a subnet to be loosely.
Last Listener Query
Interval (1-25)
The maximum amount of time between group-specific query messages, including
those sent in response to done-group messages. You might lower this interval to
reduce the amount of time it takes a router to detect the loss of the last listener of a
group.
Data Driven Group
Expiry Time (1-65535)
Enter the data driven group expiry time value.
Querier State
This allows the Switch to be specified as an MLD Querier (sends MLD query packets)
or a Non-Querier (does not send MLD query packets). Set to enable or disable.
Fast Done
Enable or disable the fast done feature.
State
Used to enable or disable MLD snooping for the specified VLAN. This field is
Disabled by default.
Report Suppression
Enable or disable the report suppression features.
Data Driven Learning
State
Enable or disable data driven learning of MLD snooping groups.
Data Driven Learning
Aged Out
Enable or disable the age out function for data driven entries.
Version
Specify the version of MLD packet that will be sent by this port.
Querier Role
Displays the querier role.
Click the Apply button to accept the changes made.
Click the <<Back button to discard the changes made and return to the previous page.
After clicking the Modify Router Port link, the following page will appear:
Figure 4-56 MLD Snooping Router Port Settings window
The fields that can be configured are described below:
Parameter Description
Unit
Select the unit to configure.
Static Router Port
This section is used to designate a range of ports as being connected to multicast-
