4T40–E AUTOMATIC TRANSAXLE 5A – 7
DAEWOO V–121 BL4
RANGE REFERENCE
Range
Park/
Neutr
al
Rever
se
D 3 2 1
Gear
N R 1st 2nd 3rd 4th 1st 2nd 3rd 1st 2nd 3rd** 1st 2nd***
1–2 Shift
Solenoid
ON ON ON OFF OFF ON ON OFF OFF ON OFF OFF ON OFF
1–2 Shift
Solenoid
OFF OFF OFF OFF ON ON OFF OFF ON OFF OFF ON OFF OFF
2nd
Clutch
– – – A A* A* – A A* – A A* – A
2nd Roll-
er Clutch
– – – H O – – H O – H O – H
Int./4th
Band
– – – – – A – – – – A – – A
Reverse
Clutch
– A – – – – – – – – – – – –
Coast
Clutch
– – – – – – A A A A A A A A
Input
Sprag
– – H H H O H H H H H H H H
Direct
Clutch
– – – – A A – – A – – A – –
Forward
Clutch
– – A A A A* A A A A A A A A
LO/Rev
Band
A A – – – – – – – – – – A –
LO Roll-
er Clutch
– – H O O O H O O H O O H O
A = Applied
H = Holding
O = Overrunnig
ON = The solenoid is energized.
OFF = The solenoid is de–energized.
* = Applied with no load.
** = Manual Second–Third gear is only available above
approximately 100 km/h (62 mph).
*** = Manual First–Second gear is only available above
approximately 60 km/h (37 mph).
NOTE: Manual First–Third gear is also possible at high ve-
hicle speed as a safety feature.
