7A – 20IHEATING AND VENTILATION SYSTEM
DAEWOO V–121 BL4
Installation Procedure
1. Install the bulb into the holder and turn the bulb to
the right.
2. Install the control assembly case halves.
S Pass the connector for the vacuum switch
through the hole in the rear assembly case part.
S Be sure to align the flats onmating control shafts
of the two case halves.
3. Install the connector into the vacuum control switch.
4. Install the control assembly. Refer to ”Control As-
sembly” in this section.
5. Connect the negative battery cable.
6. Check the knob light for proper operation.
HEATER/AIR DISTRIBUTOR CASE
ASSEMBLY
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the instrument panel carrier assembly. Re-
fer to Section 9E, Instrumentation/Driver Informa-
tion.
3. Drain the cooling system. Refer to Section 1D, En-
gine Cooling.
4. Turn the vacuum hose and pull the hose off.
