Daewoo NUBIRA - Doors Specification

SECTION : 9P
DOORS
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS 9P–1. . . . . . . . . . . . . . . . . . . . . . . . . .
FASTENER TIGHTENING SPECIFICATIONS 9P–1.
SCHEMATIC AND ROUTING DIAGRAMS 9P–3. . . . .
POWER DOOR LOCKS 9P–3. . . . . . . . . . . . . . . . . . . .
POWER WINDOWS ((FRONT AND REAR)) 9P–4. .
DIAGNOSIS 9P–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
POWER DOOR LOCKS 9P–5. . . . . . . . . . . . . . . . . . . .
POWER WINDOWS (FRONT AND REAR) 9P–7. . .
MAINTENANCE AND REPAIR 9P–9. . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9P–9. . . . . . . . . . . . . . . . . . . . .
FRONT DOOR GLASS RUN 9P–9. . . . . . . . . . . . . . . .
REAR DOOR GLASS RUN 9P–9. . . . . . . . . . . . . . . . .
FRONT DOOR SECONDARY WEATHERSTRIP 9P–
11
REAR DOOR SECONDARY WEATHERSTRIP 9P–11
DOOR LOCK STRIKER 9P–12. . . . . . . . . . . . . . . . . . .
DOOR LOCK STRIKER ADJUSTMENT 9P–13. . . . .
FRONT DOOR LOCK 9P–14. . . . . . . . . . . . . . . . . . . . .
CHILDPROOF REAR DOOR LOCK 9P–17. . . . . . . . .
INSIDE DOOR HANDLE 9P–19. . . . . . . . . . . . . . . . . .
INSIDE LOCK ROD 9P–19. . . . . . . . . . . . . . . . . . . . . . .
OUTSIDE DOOR HANDLE 9P–20. . . . . . . . . . . . . . . .
DOOR LOCK CYLINDER 9P–21. . . . . . . . . . . . . . . . . .
POWER FRONT WINDOW REGULATOR 9P–21. . .
POWER REAR WINDOW REGULATOR 9P–23. . . .
MANUAL REAR WINDOW REGULATOR 9P–24. . . .
MANUAL REAR WINDOW REGULATOR HANDLE9P
–25
FRONT DOOR ASSEMBLY 9P–25. . . . . . . . . . . . . . . .
REAR DOOR ASSEMBLY 9P–27. . . . . . . . . . . . . . . . .
DOOR HINGE 9P–29. . . . . . . . . . . . . . . . . . . . . . . . . . .
DOOR HOLD OPEN LINK 9P–29. . . . . . . . . . . . . . . . .
INSIDE CHANNEL MOLDING 9P–30. . . . . . . . . . . . . .
OUTSIDE CHANNEL MOLDING 9P–31. . . . . . . . . . .
DOOR WEATHERSTRIP 9P–31. . . . . . . . . . . . . . . . . .
DOOR SEAL TRIM 9P–32. . . . . . . . . . . . . . . . . . . . . . .
FRONT DOOR OPENING WEATHERSTRIP 9P–33.
REAR DOOR OPENING WEATHERSTRIP 9P–34. .
GENERAL DESCRIPTION AND SYSTEM
OPERATION 9P–35. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DOOR LOCK STRIKER 9P–35. . . . . . . . . . . . . . . . . . .
CHILDPROOF REAR DOOR LOCK 9P–35. . . . . . . . .
POWER DOOR LOCKS 9P–35. . . . . . . . . . . . . . . . . . .
POWER WINDOWS 9P–35. . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application NSm Lb–Ft Lb–In
Door Hinge Bolts 25 18 –
Door Hold Open Link–to–
Body Bolt
27 20 –
Door Hold Open Link–to–
Door Bolts
6 – 53
Door Lock Striker Screws 10 – 89
Door Pull Bracket Screws 3.5 – 31
