SECTION : 9M
EXTERIOR TRIM
TABLE OF CONTENTS
SPECIFICATIONS 9M–1. . . . . . . . . . . . . . . . . . . . . . . . . .
FASTENER TIGHTENING SPECIFICATIONS 9M–1.
MAINTENANCE AND REPAIR 9M–2. . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9M–2. . . . . . . . . . . . . . . . . . . . .
B–PILLAR MOLDING 9M–2. . . . . . . . . . . . . . . . . . . . . .
QUARTER WINDOW MOLDING (WAGON) 9M–2. . .
ROOF MOLDING 9M–3. . . . . . . . . . . . . . . . . . . . . . . . . .
MUD GUARDS 9M–4. . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION 9M–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EMBLEMS AND LETTERING 9M–5. . . . . . . . . . . . . . .
MUD GUARDS 9M–5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application NSm Lb–Ft Lb–In
B–Pillar Molding Screws 4 – 35
Mud Guard Bolts 1.5 – 13
Quarter Window Molding Screws 4 – 35
