SECTION : 9R
BODY FRONT END
TABLE OF CONTENTS
SPECIFICATIONS 9R–1. . . . . . . . . . . . . . . . . . . . . . . . . .
FASTENER TIGHTENING SPECIFICATIONS 9R–1.
MAINTENANCE AND REPAIR 9R–2. . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9R–2. . . . . . . . . . . . . . . . . . . . .
LUBRICATION 9R–2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
FASTENERS 9R–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ANTICORROSION MATERIALS 9R–2. . . . . . . . . . . . .
FRONT END SEALING 9R–2. . . . . . . . . . . . . . . . . . . .
COWL VENT GRILLE 9R–2. . . . . . . . . . . . . . . . . . . . . .
HOOD 9R–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HOOD HINGES 9R–4. . . . . . . . . . . . . . . . . . . . . . . . . . .
HOOD PROP ROD 9R–5. . . . . . . . . . . . . . . . . . . . . . . .
HOOD SECONDARY LATCH 9R–6. . . . . . . . . . . . . . .
HOOD LATCH RELEASE CABLE 9R–6. . . . . . . . . . . .
RADIATOR GRILLE 9R–8. . . . . . . . . . . . . . . . . . . . . . . .
FENDER 9R–9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION 9R–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BODY FRONT END 9R–14. . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application NSm Lb–Ft Lb–In
A–Pillar Fender Bolt 8 – 71
Cowl Vent Grille Screws 4 – 35
Fender Bolt (Front of Fas-
cia)
4 – 35
Front Bumper Fascia–to–
Fender Bolt
1.5 – 13
Hinge Bolts 27 20 –
Hood–to–Hinge Bolts 27 20 –
Hood Latch Bolts 8 – 71
Hood Release Handle Nuts 4 – 35
Lower Fender Bolt 8 – 71
Radiator Grille Nuts 4 – 35
Splash Shield Bolts 1.5 – 13
Upper Fender Bolts 8 – 71
