INSTRUMENT/DRIVER INFORMATION 9E – 33
DAEWOO V–121 BL4
2. Install the instrument cluster lens.
3. Install the instrument cluster. Refer to ”Instrument
Cluster” in this section.
4. Connect the negative battery cable.
FUEL GAUGE
Removal Procedure
1. Disconnect the negative battery cable.
2. Remove the instrument cluster. Refer to”Instrument
Cluster” in this section.
3. Remove the instrument cluster lens.
4. Remove the fuel gauge screws and the fuel gauge
from the cluster assembly.
To Next Page
