Daewoo NUBIRA - Remote Keyless Entry and Perimeter;Ultrasonic Anti-Theft System Specifications

SECTION : 9T
REMOTE KEYLESS ENTRY AND
PERIMETER/ULTRASONIC ANTI–THEFT SYSTEM
CAUTION : Disconnect the negative battery cable before removing or installing any electrical unit or when a tool
or equipment could easily come in contact with exposed electrical terminals. Disconnecting this cable will help
prevent personal injury and damage to the vehicle. The ignition must also be in LOCK unless otherwise noted.
TABLE OF CONTENTS
SPECIFICATIONS 9T–1. . . . . . . . . . . . . . . . . . . . . . . . . .
FASTENER TIGHTENING SPECIFICATIONS 9T–1.
SCHEMATIC AND ROUTING DIAGRAMS 9T–2. . . . .
REMOTE KEYLESS ENTRY AND ANTI–THEFT
SYSTEM (1 OF 2) 9T–2. . . . . . . . . . . . . . . . . . . . . . .
REMOTE KEYLESS ENTRY AND ANTI–THEFT
SYSTEM (2 OF 2) 9T–3. . . . . . . . . . . . . . . . . . . . . . .
CONTROL MODULE/RECEIVER CONNECTOR 9T–
4
WIRING HARNESS CONNECTORS 9T–4. . . . . . . . .
MAINTENANCE AND REPAIR 9T–5. . . . . . . . . . . . . . .
ON–VEHICLE SERVICE 9T–5. . . . . . . . . . . . . . . . . . . . .
CONTROL MODULE/RECEIVER 9T–5. . . . . . . . . . . .
SIREN 9T–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FRONT DOOR TAMPER SWITCH 9T–7. . . . . . . . . . .
REAR DECK LID TAMPER SWITCH 9T–7. . . . . . . . .
HOOD OPEN SWITCH 9T–8. . . . . . . . . . . . . . . . . . . . .
PASSWORD PROGRAMMING 9T–10. . . . . . . . . . . . .
GENERAL DESCRIPTION AND SYSTEM
OPERATION 9T–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REMOTE KEYLESS ENTRY AND ANTI–THEFT
SYSTEM 9T–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REMOTE LOCKING AND UNLOCKING 9T–11. . . . . .
SECURITY INDICATOR 9T–11. . . . . . . . . . . . . . . . . . . .
INTRUSION SENSING 9T–11. . . . . . . . . . . . . . . . . . . . .
SIREN 9T–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VEHICLE LOCATOR 9T–12. . . . . . . . . . . . . . . . . . . . . .
AUTOLOCKING (SAFETY LOCK) 9T–12. . . . . . . . . .
CONTROL MODULE/RECEIVER 9T–12. . . . . . . . . . .
FAULT OR ALARM INDICATION 9T–12. . . . . . . . . . .
PANIC BUTTON 9T–12. . . . . . . . . . . . . . . . . . . . . . . . . .
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application NSm Lb–Ft Lb–In
Hood Open Switch Mounting Screw 8 – 71
Siren Bracket Mounting Bolt 22 16 –
