5B – 2IFIVE–SPEED MANUAL TRANSAXLE
DAEWOO V–121 BL4
SPECIFICATIONS
FASTENER TIGHTENING SPECIFICATIONS
Application NSm Lb–Ft Lb–In
Backup Lamp Switch 18 13
Bearing Plate Bolts 22 16
Bearing Retainer Bolts, Right Side 25 18
Bearing–Adjusting Ring–Retainer Plate Bolt 25 18
Center Rear Transaxle Support Bracket Bolts 93 69
Clutch–Release Cylinder Bracket Bolts 75 55
Differential Cover Bolts 40 30
Fifth–Gear Fork Bolts 22 16
Fifth–Gearshift Connector Bolts 7 62
Gearshift Lever Cover Bolts 22 16
Input Driveshaft Detent Screw 15 11
Left Front Transaxle Support Bracket Bolts 47 35
Left Rear Transaxle Support Bracket Bolts 47 35
Lower Transaxle–to–Engine Bolts 75 55
Ring–Gear Bolts 70 52
Rod Clamp Bolt 14 124
Speedometer Housing Retaining Bolt 4 35
Speedometer–Driven Gear Bolt 5 44
Support Bracket Bolt 7 62
Transaxle Cover Bolts, Bigger 20 15
Transaxle Cover Bolts, Smaller 15 11
Upper Transaxle–to–Engine Bolts 75 55
