DOHC ENGINE MECHANICAL 1C – 31
DAEWOO V–121 BL4
30. Install the right front splash shield.
31. Install the right front wheel. Refer to Section 2E,
Tires and Wheels.
32. Install the air filter housing.
33. Install the air filter housing bolts.
Tighten
Tighten the air filter housing bolts to 8 NSm (71 lb–in).
34. Connect the air intake tube to the throttle body.
35. Connect the breather tube to the valve cover.
36. Connect the intake air temperature sensor connec-
tor.
37. Connect the negative battery cable.
TIMING BELT
Removal Procedure
1. Disconnect the negative battery cable.
2. Disconnect the intake air temperature sensor con-
nector.
3. Disconnect the air intake tube from the throttle
body.
4. Disconnect the breather tube from the valve cover.
