9A – 6IBODY WIRING SYSTEM
DAEWOO V–121 BL4
Fuse CircuitRating/Source
EF33 10A B+ A/C Compressor Relay,
A/C Compressor, D38
(diode)
EF34 25A B+ Headlamp Relay, EF30,
EF25, EF31, EF26, High
Headlamp Switch, Passen-
ger Switch
EF35 10A B+ Horn Switch and Horn
EF37 15A B+ Fog Lamp Relay, Front Fog
Lamps
F1 (Fuse) 15A EF6 Ign 1 Relay, Engine Control
Module, CMP
F2 10A EF6 HVAC Switch
F3 15A EF6 Hazard Switch/Turn Signal,
Digital Clock
F4 25A EF6 Wiper Switch, Intermittent
Wiper Relay, Wiper Motor,
Rear Wiper Motor, Rear
Wiper Motor Switch
F5 10A EF6 ABS Warning Lamp, Chime
Module, Transmission
Range Switch, Instrument
Cluster. BTSI Solenoid
F6 10A EF6 SIR System
F7 10A EF6 Backup Switch
F8 10A EF6 Cruise Control, Immobilizer
F9 15A EF6 Radio, Key Interlock Sole-
noid, Cigarette Lighter
F10 10A EF1 Instrument Cluster
F12 10A EF1 Engine Immobilizer
F13 15A EF1 Anti–Theft System
F14 10A EF1 Data Link Connector
F15 10A EF5 Ign 2 Relay, A/C Relay, De-
fogger Relay, ABS Relay,
ABS EBCM
