Figure 4-160
On the fish eye displayed zone, left click mouse or move to confirm the position.
On the PTZ camera displayed zone, use the following buttons to adjust the PTZ camera position.
Electronic mouse, move it on the interface
to control the PTZ direction.
Fast positioning button. Click it first and
then click any position in the video. Left
click mouse, you can view the video from
the specified position.
It is to control PTZ movement speed. The
higher the value is, the faster the speed
is.
For example, the step 8 speed is faster
than step 1.
Click add button and then click to save.
Now you complete one group position, you can view at the list. See Figure 4-161.
Figure 4-161
Repeat the above steps to set at least three group positions.
Note
For one PTZ camera, there must be three calibration groups. System max supports 8 group
positions. Please make sure the calibration position is accurate.
For the first calibration group position, please select the reference objects at the far distance to
enhance the trigger accuracy.
Click OK button to complete the calibration setup, you can go back to the smart track interface, the status
is shown as .
