Dahua HCVR82**A-S3 Series - Page 381

369
4
Blue
2
RXD
5
White and blue
3
TXD
3
White and green
5
GND
Please refer to the following figure for straight cable connection information.
Please refer to the following sheet for straight connection information.
RJ45（T568B）
RJ45 (Network cable）
RS232
Signal Description
4
Blue
3
RXD
5
White and blue
2
TXD
3
White and green
5
GND
Note:
 This manual is for reference only. Slight difference may be found in the user interface.
 All the designs and software here are subject to change without prior written notice.
 All trademarks and registered trademarks mentioned are the properties of their respective
owners.
 If there is any uncertainty or controversy, please refer to the final explanation of us.
 Please visit our website or contact your local retailer for more information.
