Table 36: Drive Control Word (FC Profile) (continued)
Coil 0 1
04 Coast stop No coast stop
05 Quick stop No quick stop
06 Freeze frequency No freeze frequency
07 Ramp stop Start
08 No reset Reset
09 No jog Jog
10 Ramp 1 Ramp 2
11 Data not valid Data valid
12 Relay 1 off Relay 1 on
13 Reserved
14 Set up LSB
15 Reserved
16 No reversing Reversing
Drive Status Word (FC Profile)
Table 37: Drive Status Word (FC Profile)
Coil 0 1
33 Control not ready Control ready
34 Drive not ready Drive ready
35 Coast stop Safety closed
36 No alarm Alarm
37 Not used Not used
38 Not used Not used
39 Not used Not used
40 No warning Warning
41 Not at reference At reference
42 Local mode Remote mode
43 Out of frequency range In frequency range
44 Stopped Running
45 Not used Not used
46 No voltage warning Voltage warning
88 | Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254
Application Guide | iC2-Micro Frequency Converters
