Application Guide | iC2-Micro Frequency Converters
Table 43: Query
Field name Example (hex)
Follower address 01 (drive address)
Function 05 (write single coil)
Coil address HI 00
Coil address LO 40 (64 decimal) Coil 65
Force data HI FF
Force data LO 00 (FF 00 = ON)
Error check (CRC) –
Response
The normal response is an echo of the query, returned after the coil state has been forced.
Table 44: Response
Field name Example (hex)
Follower address 01
Function 05
Force data HI FF
Force data LO 00
Quantity of coils HI 00
Quantity of coils LO 01
Error check (CRC) –
6.1.7.6.4 Preset Single Register (06 hex)
Description
This function presets a value into a single holding register.
Query
The query telegram specifies the register reference to be preset. Register addresses start at 0, that is, register 1 is addressed as 0.
For example, write to P 5.4.2 Operation Mode, register 999. Register 999 is parameter number * 10-1, as the parameter number is 100 for
P 5.4.2 Operation Mode.
Table 45: Query
Field name Example (hex)
Follower address 01
Function 06
Starting address HI 03 (register address 999)
Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254 | 93
