Danfoss iC2 User Manual

Selection number Selection name
0 Off
1 On
7.3.5 Output Current Limit (Menu Index 2.7)
P 2.7.1 Output Current Limit %
Enter the current limit for motor and generator operation. The parameter is changed automatically if P 4.2.2.3 Nominal Motor Current is
updated.
Default value: Size Related Parameter type: Range (0–1000)
Parameter
number:
418 Unit: %
Data type: uint16 Access type: Read/Write
This is a true current limit function that continues in the oversynchronous range. However, due to field weakening, the motor torque at
current limit drops accordingly when the voltage increase stops above the synchronized motor speed.
P 2.7.2 Current Limit K
p
Enter the proportional gain for the current limit controller. Selecting a higher value makes the controller react faster but may reduce
stability.
Default value: 100 Parameter type: Range (0–500)
Parameter
number:
1430 Unit: %
Data type: uint16 Access type: Read/Write
P 2.7.3 Current Limit T
i
Enter the integration time for the current limit controller. Selecting a lower value makes the controller react faster but may reduce
stability.
Default value: 0.02 Parameter type: Range (0.002–2.000)
Parameter
number:
1431 Unit: s
Data type: uint16 Access type: Read/Write
P 2.7.4 Current Lim Ctrl, Filter Time
Enter the filter time period for the low-pass filter of the current limit control. The filter uses the average value over the period. Setting a
shorter period makes the control react faster to changes in current.
Default value: 5 Parameter type: Range (1.0–100.0)
Parameter
number:
1432 Unit: ms
118 | Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254
Application Guide | iC2-Micro Frequency Converters
