Parameter index Parameter name Example setting Parameter number
5.5.3.9 Reference 3 Source [11] Local Bus Reference 317
5.5.2.1 Coasting Select [3] Logic OR 850
5.5.2.2 Quick Stop Select [3] Logic OR 851
5.5.2.4 Start Select [3] Logic OR 853
5.5.2.5 Reversing Select [3] Logic OR 854
9.4.1.2 T13 Digital Input [8] Start 510
9.4.1.3 T14 Digital Input [10] Reversing 511
9.4.1.4 T15 Digital Input [1] Reset 512
9.4.1.5 T17 Digital Input [14] Jog 513
5.3 Setting up the Drive using Quick Access via Control Panel
The following steps shows the quick access setup.
1. Power up the drive.
2. Press Home/Menu button on the control panel for accessing the menu structure.
3. Select QACC, and enter q1 Motor Data to first select motor type using P 4.2.1.1 Motor Type.
4. Set the value of motor data parameters, in sequence, based on the selected motor type.
5. Execute Automatic Motor Adaptation (AMA), if needed. See 5.4.5 Automatic Motor Adaptation (AMA).
6. Select application type in q2 Application Selection and wiring I/O terminals accordingly. For more information, see 5.5.1
Application Selection Overview.
7. Enter q3 Motor Control to configure reference limitations, output limitations, and ramp time.
8. Press REM/LOC, to set the drive in remote operation.
9. To start the drive by I/O terminals.
5.4 Motor Configuration
5.4.1 Motor Configuration Overview
The setup examples in this chapter describe motor configuration.
NOTICE
The parameters specified in motor configuration, cannot be adjusted when the motor is running.
The configuration setup contains, menu index, parameter name, recommended parameter setting, and parameter number. The
parameter number is a unique identification reference for the parameter. For detailed description on a parameter, refer Chapter
Parameter Descriptions.
5.4.2 Asynchronous Motor Setup
1. For asynchronous motor setup, set the following parameters:
50 | Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254
Application Guide | iC2-Micro Frequency Converters
