Table 29: Conversion
Conversion index Conversion factor
74 3600
2 100
1 10
0 1
-1 0.1
-2 0.01
-3 0.001
-4 0.0001
-5 0.00001
6.1.6.2.13 Process Words (PCD)
The block of process words is divided into 2 blocks of 16 bits, which always occur in the defined sequence.
Table 30: Process Words (PCD)
PCD 1 PCD 2
Control telegram (master->follower control word) Reference value
Control telegram (follower->master) status word Present output frequency
6.1.6.3 Examples
6.1.6.3.1 Overview of Examples
Bits 0–11 transfer parameter numbers. For more information on parameter number, see 7.1 Reading the Parameter Table. As an example,
for P 5.4.2 Operation Mode, the parameter number is 100.
6.1.6.3.2 Writing a Parameter Value
Change P 5.8.2 Motor Speed High Limit [Hz] to 100 Hz.
Write the data in EEPROM.
PKE = E19E hex - Write single word in P 5.8.2 Motor Speed High Limit [Hz]. The parameter number is 414.
l IND = 0000 hex.
l PWE
HIGH
= 0000 hex.
l PWE
LOW
= 03E8 hex.
Data value 1000, corresponding to 100 Hz, see 6.1.6.2.12 Conversion.
The telegram looks like the following illustration.
82 | Danfoss A/S © 2024.03 AB413939445838en-000301 / 130R1254
Application Guide | iC2-Micro Frequency Converters
