Table 15: Default Settings (continued)
Category Parameter index Parameter name Default setting Parameter number
9.5.2.1 T33 mode [1] Voltage Mode 619
9.5.2.2 T33 High Voltage 10V 611
9.5.2.3 T33 Low Voltage 0.07V 610
9.5.2.6 T33 High Ref./Feedb.
Value
50 615
AI1 - T33
9.5.2.7 T33 Low Ref./Feedb.
Value
0 614
9.5.1.1 T31 Mode [0] 0-20mA 690AO1 - T42
9.5.1.2 T31 Analog Output *[100] Output Fre-
quency
691
Relay 9.4.3.1 Function Relay [9] Fault 540
5.5.3.5 Reference Function [0] Sum 304
5.5.3.7 Reference 1 Source [1] Analog Input 33 315
5.5.3.8 Reference 2 Source [2] Analog Input 34 316
External reference
5.5.3.9 Reference 3 Source [11] Local Bus Refer-
ence
317
5.9.2 Jog Reference * 5.0 311Jog
5.9.1 Jog Ramp Time * 3s 380
5.5.3.3 Reference Maximum 50. If [1] North Amer-
ica is selected for
P 1.2.1 Regional
Settings, the default
value is 60.)
303Reference limits
5.5.3.4 Reference Minimum 0 302
5.5.3 Configuring Process Control Mode
Process control mode is suitable for applications which requires monitoring and adjusting of a process to give the desired output. With
process control, the frequency converter is widely used to enable quality maintenance, improve performance, increase efficiency, and
decrease cost.
NOTICE
In application and system requirements, make sure to set parameters P 5.5.3.2 Reference/Feedback Unit, P 5.5.3.3 Reference Max,
P 5.5.3.4 Reference Minimum, P 9.5.2.6 T33 High Ref./Feedb. Value, P 9.5.2.7 T33 Low, Ref./Feedb. Value, P 9.5.3.6 T34 High Ref./
Feedb. Value, and P 9.5.3.7 T34 Low Ref./Feedb. Value properly. Set these parameters according to the application's requirements.
